Overview
Various versions for various application domains (such as subterranean cables, trailing cables, Zone 1 and Zone 2 hazardous zones, etc.)
Double shielding provides high protection against interference.
Bus cable that resists flames (non-halogenated)
Thanks to printed meter markings and UL certifications, measuring length is made simple.
.
Application
To accommodate various application types, many cable types are available for the installation of PROFIBUS DP networks. Bus cables on this list should be utilized at all times. Refer to the PROFIBUS network handbook for further details on network configuration.
UL certifications
For network cables, UL listing (safety standard) is particularly important for the US and Canadian markets. Depending on where the cable is run inside the building, different approvals are needed. This is applicable to any cables that need to be mounted on cable racks that are fastened to the building in order to be routed from a computer to a remote control cabinet. The term "GP" (General Purpose) is appended to cables bearing UL certification.
permission from ex
Cables for intrinsically safe PROFIBUS DP applications have "IS" (intrinsically safe) added to their names
| MLFB no: | DESCRIPTION |
|---|---|
| 6ES7972-0BA52-0XA0 | SIMATIC DP, Connection plug for PROFIBUS up to 12 Mbit/s 90° cable outlet, Insulation displacement method FastConnect, without PG socket 15.8x 59x 35.6 mm (BxHxD) |
| 6ES7972-0BB52-0XA0 | SIMATIC DP, Connection plug for PROFIBUS up to 12 Mbit/s 90° cable outlet, Insulation displacement method FastConnect, With PG receptacle 15.8x 59x 35.6 mm (BxHxD) |
| 6GK1500-0FC10 | PROFIBUS FC RS 485 plug 180 PROFIBUS connector with FastConnect connection plug and axial cable outlet for Industry PC, SIMATIC OP, OLM, Transfer rate: 12 Mbit/s, terminating resistor with isolating function, plastic enclosure. |
| 6GK1905-6AA00 | PROFIBUS FastConnect stripping tool, Stripping tool for fast stripping of the PROFIBUS FastConnect bus cable . |
| 6GK1905-6AB00 | PROFIBUS FastConnect blade cassettes, spare blade cassettes for the PROFIBUS FastConnect stripping tool, 1 pack=5 units. |
